Victron ARGO BCD 802

Diode combiner for parallel connection of batteries and power supply of common equipment, maximum current 80 A, for 2 batteries and 12/24 V systems.
Diode Battery Combiners are used to guarantee continuous DC power to mission critical equipment, such as an electronic engine control system. With a Diode Battery Combiner two or more DC power sources can be used in parallel to supply the mission critical load. Failure of one source will not interrupt power to the critical load.

The Argo Battery Combiners feature a low voltage drop thanks to the use of Schottky diodes: at low current the voltage drop is approximately 0,3 V and at the rated output approximately 0,45 V.

Warning: Hot surface, mount the Argo Diode Battery Combiner on non-flammable surface only!

SPECIFICATIONS

Maximum continuous current: 80 A
Number of batteries: 2
Connection: M6 bolts
Weight: 0,8 kg (1.8 lbs)
Dimensions: 120 x 75 x 60 mm (4.7 x 3.0 x 2.4 inch)
