SOLAX POCKET Wi-Fi + LAN INTERFACE

SOLAX Pocket Wi-Fi + LAN Module

The SOLAX Pocket WiFi+LAN communication module allows remote monitoring and management of inverters via Wi-Fi or Ethernet connection.

This professional module offers easy “Plug & Play” installation and ensures stable data transmission between SOLAX inverters and the cloud monitoring platform. Thanks to its IP65 protection, the device is protected against dust and splashing water, allowing trouble-free deployment in various environments.

The module supports Modbus TCP and IEEE2030.5 protocols for integration with different monitoring systems. The offline data storage function ensures that no data is lost even during temporary connection outages.

• Easy “Plug & Play” installation for quick setup
• Dual connectivity – Wi-Fi 2.4 GHz and Ethernet 10/100 Mbit/s
• High IP65 rating for protection against dust and splashing water
• Stable data transmission with 5-minute update interval
• Offline data storage with automatic transmission recovery after reconnection
• Live monitoring with 10-second data update
• 3 dBi antenna gain for reliable wireless connection
• Support for Modbus TCP and IEEE2030.5 protocols

Real-time Monitoring

With 10-second live monitoring, you always have up-to-date information about the performance of your photovoltaic system. Thanks to the SOLAX cloud platform, you can monitor performance, energy production, and other parameters from anywhere, anytime.

Reliability in All Conditions
With a wide operating temperature range from -35 °C to +60 °C and a robust design, the module can operate reliably in various climatic conditions.

BASIC SPECIFICATIONS

Model: Pocket Wi-Fi + LAN
Power Supply: DC 5 V/ 200 mA
Wireless Module: Wi-Fi 2.4 GHz
Ethernet: 10/100 Mbit/s
Antenna Gain: 3 dBi
Data Transmission Interval: 5 minutes
Data Monitoring Interval: 10 seconds
Dimensions: 112 × 45.7 × 28.5 mm
Weight: 80 ±10 g
Protection Rating: IP65
Operating Temperature Range: -35 to +60 °C
Compatibility: X1-Mini G3.1, X1-Boost G3.3, X3-MIC G2, X3-Pro G2, X3-Mega G2, X3-Forth, X1 Hybrid G4.1 (version D), X3-Hybrid G4.2 (version D), X1-Fit G4, X3-Fit G4, X3 Hybrid G4.3, X3 Ultra
