TINYCONTROL Universal DIN rail-mounted splitter

Tinycontrol TNCUSDIN

Universal DIN rail-mounted distributor with terminal blocks helps organize cabling in complex installations using the LAN controller.

This practical distributor is designed for professional electrical installations where efficient connection of multiple devices is required. Thanks to spring terminals, it allows quick and reliable wire connections without the need for tools, which significantly simplifies installation and system maintenance.

The device is ideal for use in industrial applications, building automation, and wherever power and communication lines need to be distributed among multiple devices while keeping cabling clear and organized.

• Allows multiplication of power outputs from the LAN controller (e.g., +5 V and GND) to power more sensors
• Ensures easy distribution of A+ and B- lines from the LAN controller (LK4) to multiple Modbus devices
• Includes 2 common terminal block fields with 4 and 8 shared connections for distributing power lines
• Provides 2 terminal block fields with 6 pairs of connectors for connecting up to 6 devices to one Modbus RTU bus
• Supports wire cross-sections from 0.2–1.5 mm² (28–14 AWG)
• Operates with a maximum voltage of 56 V and max. current of 2 A
• Standard 35 mm DIN rail mounting for easy integration into electrical cabinets

Connecting analog sensors
The distributor allows efficient multiplication of power outputs from the LAN controller (e.g., +5 V and GND) to power multiple analog sensors from a single source. This significantly simplifies installation and reduces the amount of wiring needed.

Modbus RTU bus expansion
The device ensures easy distribution of communication lines A+ and B- from the LAN controller (LK4) to multiple Modbus devices, with each device having its own terminal pair while remaining on the common bus.

Professional design
The distributor is designed for professional use with an emphasis on reliability and easy installation. Spring terminals ensure high-quality and durable connections, while standard DIN rail mounting enables simple integration into existing electrical cabinets.

BASIC SPECIFICATIONS

Type: universal distributor with terminal blocks
Mounting: DIN rail, 35 mm
Supported wire cross-section: 28–14 AWG (0.2–1.5 mm²)
Maximum voltage: 56 V
Maximum current: 2 A
Number of terminal block fields: 4 (2× common, 2× paired)
Number of connectable Modbus devices: up to 6 (LAN controller + 5 modules)
