Victron solar panel 130Wp/12V, Poly

Solar polycrystalline panel BlueSolar 130 Wp (12 V) series 4a with a maximum (peak) power output of 130 Wp. Designed for systems with a working voltage of 12 V.

• Low voltage temperature coefficient increases efficiency at high temperatures.
• Excellent performance in low light conditions and high light sensitivity across the entire solar spectrum.
• 25-year limited warranty on output power and operating parameters (10 years 90% + 25 years 80% output power).
• Sealed waterproof multifunction junction box provides a high level of safety.
• High-performance bypass diodes minimize power drop caused by shading.
• Robust anodized aluminum frame facilitates rooftop installation into a wide range of mounting systems.
• High-transmission tempered glass ensures increased rigidity and impact resistance.
• Pre-wired quick-connect system with MC4-type connectors.
• Advanced EVA (ethylene vinyl acetate) encapsulation system with triple-layer protective foil meets the strictest safety requirements for high-voltage operation.

High-quality solar panel with a 25-year manufacturer performance guarantee. More information can be found below in related documents.

This panel has 36 cells and a solid aluminum frame. It is equipped with special mechanically durable tempered glass with high light transmittance.
The waterproof output features integrated bypass diodes for reverse current protection and is highly resistant to extreme weather conditions such as high and low temperatures, frost, heavy rain, or wind.

The panel includes a junction box with cables and MC4 connectors. Cable length is 90 cm.

We usually have panels in stock in Prague with fast delivery within the Czech Republic and Slovakia within two days.

TECHNICAL SPECIFICATIONS

Panel type: polycrystalline
Number of cells: 36
Max. power (Pmax): 130 W
Max. power voltage (Vmp): 18.5 V
Max. power current (Imp): 7.02 A
Dimensions: 1200 × 668 × 30 mm
Color: blue (silver frame)
