EZVIZ DC Transformer (for Intercom)

EZVIZ DC Transformer

Power transformer designed for EZVIZ video doorbell with 24 V (DC) output voltage and 36 W power.

This transformer is designed to power EZVIZ brand video doorbells and home intercoms that require safe low voltage 24 V (DC). It converts standard mains voltage 100-240 V (AC) to stabilized 24 V direct current with a maximum output current of 1.5 A.

The transformer features a compact design in a plastic housing with DIN rail mounting, allowing for professional concealed installation in a distribution box. The device is equipped with comprehensive protection against overload, short circuit, and overheating, ensuring safe operation and protecting connected devices from damage.

• Universal input voltage 100–240 V (AC)
• Output voltage 24 V (DC) with maximum current 1.5 A and power 36 W
• High efficiency of 89% for economical operation with minimal losses
• Mounting on standard DIN rail for professional installation in distribution box
• Wide operating temperature range from -30 °C to +70 °C
• Plastic housing with comprehensive protection against overload, short circuit, and overheating

Professional Installation
The transformer is designed for mounting on a standard 35 mm DIN rail, allowing for clean and safe connection in a distribution box. Concealed installation eliminates the need for visible adapters and cabling.

Wide Compatibility
The device is compatible with most intercom systems and video doorbells requiring 24 V (DC) power supply. It operates at a frequency of 47–63 Hz, covering standards used in Europe and other regions.

Durability and Safety
Operating temperature range from -30 °C to +70 °C and humidity resistance up to 90% (non-condensing) ensure reliable operation even in demanding conditions. Integrated protective functions protect both the transformer and connected devices.

BASIC SPECIFICATIONS

Input voltage: 100–240 V (AC)
Output voltage: 24 V (DC)
Frequency: 47–63 Hz
Output current: 1.5 A
Power: 36 W
Efficiency: 89 %
Operating temperature: -30 to +70 °C
Humidity: ≤ 90 % (non-condensing)
Dimensions: 90 × 54.5 × 35 mm
Weight: 123 g
