Planet Split-Core Current Transformer with 333mV Output (100A Rated Current, 16mm diameter)

PLANET CT-100A-16

Split-core current transformer with a rated primary current of 100 A and a standard output of 333 mV AC, designed for measuring alternating current without the need to interrupt existing conductors.

Thanks to its split-core design, the transformer allows quick and easy installation into existing distribution boards without disconnecting conductors. The 16 mm aperture diameter is suitable for conductors used in applications with current loads up to 100 A. The 333 mV AC output signal is compatible with PLANET smart energy meters with a 333 mV CT input.

The transformer is ideal for use in energy consumption monitoring, power management, building automation and applications involving electrical equipment. The Nylon, Resin 94-V0 housing material ensures durability and safe operation. The included 2 m cable facilitates connection to the measuring device.

• Split core allows installation around existing conductors without disconnecting them.
• Rated primary current of 100 A with a 16 mm aperture diameter for standard conductors.
• Standard 333 mV AC output compatible with PLANET smart energy meters with 333 mV CT input.
• Measurement accuracy of 0.5% F.S. for reliable AC current sensing.
• Phase linearity error ≤ 30 minutes for precise phase shift measurement.
• Operating voltage up to 720 V AC and frequency range from 50 Hz to 1 kHz.
• Insulation resistance of 100 MΩ at 500 V DC and dielectric strength of 4000 V AC for 10 seconds.
• Nylon, Resin 94-V0 housing with CE certification.
• Included cable AWM1015, 22 AWG (0.34 mm2), black-and-white twisted pair, length 2 m.

Output conductor wiring
The output conductors are color-coded: S1 (white conductor) connects to terminal K, S2 (black conductor) connects to terminal L of the measuring device.

BASIC SPECIFICATIONS

Sensor type: split-core current transformer
Rated primary current: 100 A
Rated secondary output: 333 mV AC
Accuracy: 0.5% F.S.
Phase linearity error: ≤ 30 minutes
Operating voltage: ≤ 720 V AC
Frequency range: 50 Hz to 1 kHz
Aperture diameter: 16 mm
Cable length: 2 m
Cable: AWM1015, 22 AWG (0.34 mm2), black-and-white twisted pair
Output conductor wiring: S1 (white): terminal K; S2 (black): terminal L
Dimensions: 49 × 33.9 × 37.8 mm
Weight: 100 g
Housing material: Nylon, Resin 94-V0
Operating temperature: -15 to +50 °C
Insulation resistance: 100 MΩ at 500 V DC
Dielectric strength: 4000 V AC for 10 seconds
MTBF: > 50,000 hours at +25 °C
Certifications: CE, FCC Part 15 Class A
