TINYCONTROL temperature sensor DS18B20U for LAN controller

Digital temperature sensor with cable and RJ-11 connector as standard Lan Controller. The sensor in the digital 1-Wire bus standard, compatible with DS18B20 sensors. Each sensor is programmed with a serial ID number, which allows for reading multiple sensors on one bus. The aluminum substrate enables very fast heat transfer to the sensor.

• Programmable transducer accuracy: 9-12 bit
• Power supply: 2.5 ÷ 5.5 V DC
• ESD protection: > 8000 V
• Typical current draw in standby mode: 1 uA @ 3 V
• Typical current draw during conversion: 0.6 mA @ 3 V

SPECIFICATIONS

Measurement range: -55 to +125 °C
Measurement accuracy: +/- 0,4 °C (in the temperature range -10 to +85 °C)
Cable length: 105 cm
