2N Clip - Ethernet

2N Clip Ethernet

IP door station with a 4.3" display, designed for residential projects.

The unit combines IP video, an integrated microphone and 2 W speaker with operation on the 2N OS platform. Remote management is provided by support for the My2N Management Platform. Power is supplied exclusively via PoE 802.3af (class 0; 48 V DC, 200 mA), so no separate power supply is required. The unit is controlled by 3 capacitive buttons. Factory settings can be restored by pressing and holding the RESET button.

• IP answering unit with a 4.3" display and 480 × 272 px resolution for residential installations.
• Doorbell input with switching contact (NO, 12 V/20 mA DC) for direct connection of a doorbell button.
• LAN 10/100BaseT network interface via RJ-45 connector, recommended cabling Cat5e or higher.
• Operation on the 2N OS platform with remote management via the My2N Management Platform.

BASIC SPECIFICATIONS

Power supply: PoE 802.3af class 0; 48 V DC, 200 mA
Display: 4.3", resolution 480 × 272 px
Video codec: H.264
Audio codecs: G.711a/u, G.722, G.729, L16/16 kHz
Microphone: integrated
Speaker: integrated, 2 W
Controls: 3 capacitive buttons
LAN interface: 10/100BaseT, RJ-45
Induction loop: no
Recommended cabling: Cat5e or higher
Doorbell input: switching contact (NO), 12 V/20 mA DC
Operating temperature: 0 to +50 °C
Relative operating humidity: 10 to 90% (non-condensing)
Dimensions: 150 × 124 × 28 mm
Weight: 235 g
