Teltonika Router RUTX12

Powerful Dual LTE Cat 6 router is designed for mission critical applications. Two simultaneously operational LTE CAT 6 modems can provide speeds up to 600 Mbps with load balancing feature. 5 x Gigabit Ethernet ports, Wave-2 802.11ac Dual Band WiFi, Bluetooth LE and USB interfaces with RutOS software and security features make this device irreplaceable in applications where loosing connection is not an option.

WIRELESS
Wireless mode: 802.11b/g/n/ac (WiFi 5) with data transmission rates up to 867 Mbps (Dual Band, MU-MIMO), 802.11r fast transition, Access Point (AP), Station (STA)
WiFi security: WPA2-Enterprise-PEAP, WPA2-PSK, WPA-PSK, WEP; AES-CCMP, TKIP, Auto Cipher modes, client separation
ESSID: ESSID stealth mode
Wireless Hotspot: Captive portal (Hotspot), internal/external Radius server, built in customizable landing page
Bluetooth LE: Bluetooth low energy (LE) for short range communication

MOBILE
Mobile module: 2 x 4G (LTE) – Cat 6 up to 300 Mbps, 3G – Up to 42 Mbps
SIM/mobile module switch: SIM cards, one for each mobile module, auto switch cases: weak signal, data limit, SMS limit, roaming, no network, network denied, data connection fail, SIM idle protection (planned)
APN: Auto APN
Bidge: Direct connection (bridge) between mobile ISP and device on LAN
Status: Signal strength, SINR, RSRP, RSRQ, Bytes sent/received, Mobile module in use
SMS: SMS status, SMS configuration, send/read SMS via HTTP POST/GET (planed), EMAIL to SMS (planed), SMS to Email (planed), SMS to HTTP (planed), SMS to SMS (planed), scheduled SMS (planed), SMS auto replay (planed), SMPP (planed)
Black/White list: Operator black/white list
Multiple PDN (planed): Possibility to use different PDNs for multiple network access and services
Band management: Band lock, Used band status display

ETHERNET
WAN: 1 x WAN port (can be configured to LAN) 10/100/1000 Mbps, compliance with IEEE 802.3, IEEE 802.3u, 802.3az standards, auto MDI/MDIX
LAN: 4 x LAN ports, 10/100/1000 Mbps, compliance with IEEE 802.3, IEEE 802.3u, 802.3az standards, auto MDI/MDIX

NETWORK
Routing: Static routing, Dynamic routing (BGP, OSPF v2, RIP v1/v2, EIGRP, NHRP)
NetSnapper (optional): Mobile connection management, data compression VPN client (not available in standard FW)
Network protocols: TCP, UDP, IPv4, IPv6, ICMP, NTP, DNS, HTTP, HTTPS, FTP, SMTP, SSL v3, TLS, ARP, VRRP, PPP, PPPoE, UPNP, SSH, DHCP, Telnet, SMNP, MQTT, Wake On Lan (WOL)
VoIP passthrough support: H.323 and SIP-alg protocol NAT helpers, allowing proper routing of VoIP packets
Connection monitoring: Ping Reboot, Wget reboot, Periodic Reboot, LCP and ICMP for link inspection
Firewall: Port forwards, traffic rules, custom rules
DHCP: Static and dynamic IP allocation, DHCP Relay, Relayd
QoS: Traffic priority queuing by source/destination (planned), service (planned), protocol or port (planned), WMM, 802.11e
DDNS: Supported >25 service providers, others can be configured manually
Network backup: VRRP, Mobile and Wired WAN options, each of which can be used as backup, using automatic Failover
Load balancing: Balance your Internet traffic over multiple WAN connections
Hotspot: Internal/external Radius server, captive portal, built in customizable landing page
SSHFS (optional): Possibility to mount remote file system via SSH protocol (not available in standard FW)

SECURITY
Authetication: Pre-shared key, digital certificates, X.509 certificates
Firewall: Pre-configured firewall rules can be enabled via WebUI, unlimited firewall configuration via CLI; DMZ; NAT; NAT-T
Attack prevention: DDOS prevention port scan prevention (SYN-FIN, SYN-RST, X-mas, NULL flags, FIN scan attacks)
VLAN: Port based and tag based VLAN separation
Mobile quota control: Set up custom data limits for both SIM cards
WEB filter: Blacklist for blocking out unwanted websites, whitelist for specifying allowed sites only
Access control: Flexible access control of TCP, UDP, ICMP packets, MAC address filter

MODBUS
Modbus TCP slave: ID filtering: Respond to one ID in range [1;255] or any Allow remote access: Allow access through WAN
Custom registers: Modbus TCP custom register block, which allows to read/write to a file inside the router, and can be used to extend Modbus TCP slave functionality
Modbus TCP master: Supported functions: 01, 02, 03, 04, 05, 06, 15, 16
Supported data formats: 8 bit: INT, UINT; 16 bit: INT, UINT (MSB or LSB first); 32 bit: float, INT, UINT (ABCD (big-endian), DCBA (little-endian), CDAB, BADC)
MQTT gateway: Gateway Allows sending commands and receiving data from Modbus Master trough MQTT broker
Modbus data to server: Protocols HTTP(S), MQTT, Azure MQTT (planned)

MONITORING & MANAGEMENT
WEB UI: HTTP, status, configuration, FW update, CLI, troubleshoot, event log, system log, kernel log
FOTA: Firmware update from server, automatic notification
SSH: SSH (v1, v2)
SMS: SMS status, SMS configuration, send/read SMS via HTTP POST/GET
CALL: Reboot, Status, Mobile data on/off, Output on/off
TR-069 (planed): OpenACS, EasyCwmp, ACSLite, tGem, LibreACS, GenieACS, FreeACS, LibCWMP, Friendly tech, AVSystem
MQTT: MQTT Broker, MQTT publisher
SNMP: SNMP (v1, v2, v3), SNMP trap
JSON-RPC: Management API over HTTP/HTTPS
MQTT: MQTT Broker, MQTT publisher
JSON-RPC: Management API over HTTP/HTTPS
Modbus: Modbus TCP status/control
RMS: Teltonika Remote Management System (RMS)

SYSTEM CHARACTERISTICS
CPU: Quad-core ARM Cortex A7, 717 MHz
RAM: 256 MB, DDR3
FLASH memory: 256 MB SPI Flash

POWER
Connector: 4 pin industrial DC power socket
Input voltage range: 9 - 50 VDC, reverse polarity protection, voltage surge/transient protection
PoE (passive): Passive PoE. Possibility to power up through LAN1 port, not compatible with IEEE 802.3af/at
Power consumption: Idle
