Ubiquiti OS2 Duplex LC UPC Fiber Patch Cable 0.5 m
Single-mode optical patch cable OS2 with duplex LC UPC connectors for high-speed indoor installations up to 100G.
The cable is equipped with duplex LC UPC connectors and uses single-mode OS2 fiber, which supports wavelengths 1310 and 1550 nm. Insertion loss ≤ 0.3 dB and back reflection ≥ 50 dB ensure reliable signal transmission even in more demanding optical paths. Cable length 0.5 m suitable for connecting devices in a rack or data distribution cabinet.
The cable sheath is made of LSZH (Low Smoke Zero Halogen) material with a diameter of 2 mm, which does not emit toxic halogen gases in the event of a fire. The yellow jacket color corresponds to the standard color coding of single-mode fiber optic cables.
BASIC SPECIFICATIONS
Fiber type: OS2 single-mode Connectors: 2× duplex LC UPC Cable length: 0.5 m Jacket diameter: 2 mm Jacket material: LSZH (Low Smoke Zero Halogen) Jacket color: yellow Corrugated length: 1310 / 1550 nm Insertion loss: ≤ 0.3 dB Back reflection: ≥ 50 dB Repeatability: ≤ 0.1 dB Connector resistance: ≤ 0.2 dB (1000 connections) Operating environment: indoor Operating temperature: -40 to +75 °C
