Digitus Kods: 520175

Digitus OnLine UPS Systems, Tower Type, 3000 VA / 3000 W

Name: Digitus OnLine UPS Systems, Tower Type, 3000 VA / 3000 W
Brand: Digitus
SKU: 520175

Nav pieejams

Ātra piegāde

Kurjers un pakomāti

Ražotāja garantija

Oficiālais izplatītājs

Preču atgriešana

14 dienu atgriešana

Konsultācija

+371 27 879 580

Apraksts

Characteristics
- Waveform: Pure sine
- Output voltage regulation: 1%
- Output frequency: 50/60 Hz
- UPS Topology: Double Conversion (Online)
- Efficiency (ECO mode): 97%
- Noise level: 50 dB
- Response time (typical): 4 ms
- Audible alarm: Yes
- Power protection features
  - Overload
  - Short circuit
  - Overheating protection
  - Low voltage protection
  - Battery discharge protection
  - Overcharge protection
- Power factor: 1
- Output operating voltage (minimum): 240 V
- Crest Factor: 3:1
- Efficiency: 92%
- Output current THD level: 3%
- Input operating voltage (maximum): 300 V
- Input frequency: 40 - 70 Hz
- Actual power: 3000 W
- Output operating voltage (maximum): 208 V
- Input operating voltage (minimum): 110 V
- Maximum configurable power: 3 kVA
Design
- Product color: Black
- Layout: Tower
- Display type: LCD
Weight and dimensions
- Product weight: 24.5 kg
- Product height: 337 mm
- Product depth: 460 mm
- Product width: 191 mm
Working conditions
- Temperature range (operation): 0 - 40 °C
- Temperature range (storage): -25 - 55 °C
- Permissible operating altitude (above sea level): 0 - 1000 m
- Relative humidity range: 20 - 95%
Packaging data
- Package width: 275 mm
- Weight with packaging: 27.4 kg
- Packaging type: Box
- Package height: 446 mm
- Package depth: 563 mm
Package contents
- Quick Installation Guide: Yes
- Cables: Power cable, RS-232, USB cable
Ports and interfaces
- Serial interface: Yes
- Number of network sockets: 8 x network socket
- AC Output Types
  - C19 panel
  - C13 panel
- Plug: C20 panel
- RS-232 port: 1
- USB port: Yes
Battery
- Charging current: 2 A
- Battery voltage: 12 V
- Battery capacity: 9 Ah
- Charging time: 4 hours
- Battery type: Lead acid (VRLA)
- Number of battery cells: 6
- Cold start: Yes
